Comprehensive Technical Capabilities
WIN-TEC ELECTRICAL provides complete turnkey power electrical systems ranging from medium-voltage (MV) substation construction to heavy industrial power distribution networks. We engineer, supply, erect, test, and commission robust electrical infrastructure compliant with CEB, LECO, and international IEC/IEEE standards.
Scope of Engineering Solutions
- Turnkey construction of 11kV, 33kV, and 132kV outdoor & indoor electrical substations
- Oil-immersed and dry-type cast resin transformer supply, installation, and dielectric testing
- Medium Voltage (MV) switchgear and vacuum circuit breaker (VCB) panels
- Heavy industrial plant power distribution and primary busduct trunking systems
- Underground armored MV/LV power cabling, jointing, and fault locating
- Power system harmonics analysis, power quality auditing, and load balancing
- Primary & secondary injection testing, protective relay calibration, and grid handover
Engineered For Zero Downtime
Every switchboard, cable containment network, and control package engineered by WIN-TEC undergoes exhaustive multi-stage Factory Acceptance Testing (FAT) before shipment.
Technical Specifications
| Voltage Ratings | LV 400V/230V, MV 11kV / 33kV, HV up to 132kV |
|---|---|
| Transformer Ratings | 100 kVA up to 5000 kVA (Oil-Cooled / Dry-Type) |
| Short Circuit Withstand | Up to 50kA for 3 seconds / 65kA for 1 second |
| Applicable Standards | IEC 62271-200, IEC 60076, BS 7671, IEEE standards |
| Testing Equipment | Omicron Secondary Injection Sets, Megger 10kV IR Testers, Hipot Test Sets |
| Grid Approvals | Compliant with CEB, LECO & international utility codes |
Typical Industry Applications
Request Technical Consultation
Submit your project details or technical single-line diagram (SLD). Our engineering department will respond within 24 hours.
Technical Brochure
Download comprehensive technical catalog, dimensions, rating curves, and single-line diagrams.
