Comprehensive Technical Capabilities
Our Cable Management System division manufactures and supplies heavy-duty cable routing solutions designed to protect and support electrical power, control, instrumentation, and telecommunication cabling. Fabricated from premium cold-rolled steel, stainless steel, and aluminum with certified corrosion-resistant coatings.
Scope of Engineering Solutions
- Perforated Cable Trays in pre-galvanized and hot-dip galvanized finish
- Heavy-Duty Cable Ladders with welded tubular rungs for high structural span
- Stainless Steel 316L Cable Trays for corrosive chemical & marine environments
- Wire Mesh Cable Baskets for clean data center and IT routing
- Cable Trunking Systems with single and multi-compartment dividers
- Engineered Unistrut framing channels, trapeze hangers, and cantilever brackets
- Fire-rated cable containment systems compliant with BS 5839
Engineered For Zero Downtime
Every switchboard, cable containment network, and control package engineered by WIN-TEC undergoes exhaustive multi-stage Factory Acceptance Testing (FAT) before shipment.
Technical Specifications
| Materials | Mild Steel, Stainless Steel (SS304 / SS316L), Aluminum |
|---|---|
| Surface Finishes | Hot-Dip Galvanized (BS EN ISO 1461), Pre-Galvanized, Epoxy Powder Coated |
| Standard Lengths | 2.44m, 3.0m, and custom project lengths |
| Width Range | 50mm to 1000mm tray and ladder widths |
| Side Rail Heights | 50mm, 75mm, 100mm, 125mm, 150mm |
| Load Capacity | Tested up to 350 kg/m safe working load (SWL) |
| Standard Compliance | NEMA VE1, BS EN 61537, IEC 61537 |
Typical Industry Applications
Request Technical Consultation
Submit your project details or technical single-line diagram (SLD). Our engineering department will respond within 24 hours.
Technical Brochure
Download comprehensive technical catalog, dimensions, rating curves, and single-line diagrams.
